Short Form Catalogue - 3

Spotlight started 40 years ago as a localmanufacturer of lighting fixtures for the performing arts.Since then, they have not only improved thetechnology of the products for worldwide professional users in the entertainment industry, but they have also increased the product range to a specific line of architectural lighting fixtures. The CompanyŒs commitment is to keep developing new solutions to better answer the market needs. Spotlight are proud to offer their Customers not only a wide selection of products combining advanced technology with aesthetic design, but also solutions to their...

Katalog auf Seite 3 öffnen
Short Form Catalogue - 4

Architectural PC, Fresnel, Profile, Par spots and Led colour changers. Compact size projectors of quality for accent lighting of shops, hotels, museums, places of worship, window displays and residential venues. > MINI FN > Fresnel, optional barndoor MINI PC > Plano-convex, optional barndoors Halogen lamps: MI FN NO (230 V) 300 W, GY 9.5 MI FN LW (24 V) 150 W G 6.35 Adjustable beam from 7.5 to 53а 110x131x172 mm - 1.3 Kg Metal halide lamps:MI FN ME MSD 200/250 W, GY 9.5 MI FN MC Mastercolour 150 W, G 12 Adjustable beam from 7.5 to 53а 110x131x308 mm - 5.6 KgMetal halide lamps:MI PC ME MSD...

Katalog auf Seite 4 öffnen
Short Form Catalogue - 5

Improved mechanical structure, special easy balancing yoke 5 coated lenses, high definition optimised optical system Housing of die-cast extruded aluminium Օ Maximum strength, minimum maintenance Sliding and reversible yoke Օ Accessory holder protected by hinged door Adjustable lamp holder tray Օ Safety microswitch that disconnects power when the fixture (lamp tray) is opened Complies with CE EN 60598-2-17. Electrical parts completly removable Halogen Zoom Profile Spots with High-efficiency Condenser Optics > Plano-Convex, halogen, optional barndoors EVO 12 H ZW EVO 12 H ZS VA 05 VA 12 VA...

Katalog auf Seite 5 öffnen
Short Form Catalogue - 6

Housing of extruded aluminium and pressed steel Sliding and reversible yoke Օ Accessory holder with double sliding guide and safety lock Complies with CE EN 60598-2-17 COM 05 F > Halogen Zoom Profile Spots fresnel, optional barndoor plano-convex optional barndoor COM 25 ZM > Fresnel, optional barndoor QS 10 F COM 05 PC COM 05 ZW COM 05 ZS > 300/500/650 W, GY 9.5Adjustable beam from 7հ to 62 150x150x251 mm - 3 Kg 300/500/650 W, GY 9.5 Adjustable beam from 5а to 56 150x150x301 mm - 3.7 Kg 300/500/650 W, GY 9.5 Adjustable beam from 23а to 40 Shaping shutters and sliding guides for gobo holder...

Katalog auf Seite 6 öffnen
Short Form Catalogue - 7

Sturdy die-cast extruded aluminium housing High efficiency optical system Օ Easy to handle; high precision focusing Zoom Followspot VD 12 H CC VD 12 M CR/HR > Halogen lamp 1200W Fast-FitAdjustable beam from 10 to 15а Fast-Fit fot easy lamp replacement Built-in manual colour changer Low Voltage lamp version available Sliding guides for size B gobo holder Iris diaphragm with black out 200x224x726 mm - 14.6 Kg Metal halide lamp 1200 W/MSR G 22 or G 38 for Hot Restrike version Adjustable beam from 7 to 18а Shaping shutters and sliding guides for size B gobo holder Iris diaphragm with black out...

Katalog auf Seite 7 öffnen
Short Form Catalogue - 8

Hot Restrike ignitor Е Microswitch disconnects power when unit is opened Time counter for lamp life Օ Electromagnetic ballast Safety net Օ 4-leaf barn-door Dimming shutter, optional DMX Օ Electronic ballast, flicker free on request Comply with CE EN 605982-17 DMX 512 Three main models for luminaires up to 5000W Օ Accepts all Spotlight fixtures (PC, Fresnel, profile spots, etc.) and most of other units commercially available Special versions for Svoboda, video projectors and other applications Օ Noise-free Over 360հ Pan, tilt up to 100 or 270а (depending on the model) Last achieved position...

Katalog auf Seite 8 öffnen
Short Form Catalogue - 9

Filter frames Barndoors Օ Hanging hooks and clamps Safety bonds Օ Colour and conversion filters, plastic film and glass Gobo holders Օ Iris diaphragms Telescopic stands Օ ScrollerӔ Colourchanger Motorised dimming shutters with DMX 512 control Օ Objective lenses Mechanical, manual and DMX-controlled dimmers for discharge lamps Օ Halogen and discharge lamps of all sizes Functional as both uplighter or downlighter Colour Filter Frame (optional) Safety net Օ Comply with CE EN 60598-2-17 RA 4 > Asymmetrical Floodlight DOM 1000 D 2 X 2 P / D 2 X 2 M > Linear halogen lamps R7s- 625-1000-1250 W...

Katalog auf Seite 9 öffnen
Short Form Catalogue - 12

CT-SP RI EN / 200902 Note: To ease readability, the objects shown are not reproduced in their correct proportions. Spotlight reserve the right to change any data in this catalogue without prior notice. Release January 2009. All Rights Reserved. >
