FARETTO - MINI FARETTO 16 STEALTH - STEALTH LINEAR 68

BELVEDERE DESIGNED BY ANTONIO CITTERIO WITH TOAN NGUYEN descriPtion Device for exterior lighting with protection degree IP55, available in different heights of sizes and types of lighting sources, from the latest innovation remote phosphor LED to the compact discharge lamp. belvedere spot Wall: an up-to-360º adjustable projector on the horizontal axle suitable for wall installations and without recessed box. belvedere spot: one or two adjustable projectors (double rotation, vertical and horizontal axle) suitable for floor installations (tiled or land floor), in three heights of different...

descriPtion Floor, wall or ceiling luminaire for indoor/outdoor use. IP55 protection. Insulation Class 1. Three non-dimmable light sources: • 24W 2G11 fluorescent light • 20W PGJ5 metal halide light • Power LED. The luminaire consists of: • floor/wall/ceiling fitting in diecast 46100 aluminum with “yellow alodine” non-corrosive protection • extruded anti corodal 6010 aluminum alloy body with phosphochromed non-corrosive protection • extruded anti corodal 6010 aluminum alloy head with phosphochromed non-corrosive protection • extruded anti corodal 6010 aluminum front cap with phosphochromed...

FARETTO AND MINI FARETTO DESIGNED BY PIERO LISSONI descriPtion Range of outdoor spotlights, base mounted, wall or façade versions, in two sizes: diam. 99mm, diam. 138mm. For halogen or metal halide lamps. Die-cast aluminum, powdercoated body. 6mm tempered glass cover. Polymer anti-glare screening cone inside the body. Inner ring for lamp mounting. Silicone seals. Finishes: matt white (01), grey (72), matt black (04) and dark brown (MM). reFLectors Super-pure aluminum reflectors with silver-anodized, glossy finish. LamPs halogen: - PAR 16, GZ10 lamp holder, 50W (beam angles: 25° - 50°) -...

KTRIBE F3 OUTDOOR DESIGNED BY PHILIPPE STARCK TECHNICAL DATA SHEET: PAGE 113 descriPtion Floor lamp providing diffused light for outdoor use. Die-cast aluminium base and stem support. Galvanized structural parts to protect against atmospheric agents. Chrome finish. Injection-moulded polycarbonate internal diffuser and bulb-holder. Exterior diffuser made from braided coloured PVC tubes and inner frame from polyester painted phosphor-chromed aluminium bars. Steel cataphoresis treated counterweight for effective protection against atmospheric agents. Phosphor-chromed die-cast aluminium outer...

SUPERARCHIMOON OUTDOOR TECHNICAL DATA SHEET: PAGE 113 DESIGNED BY PHILIPPE STARCK descriPtion Floor luminaire for outdoor use providing direct and diffused light. Outer diffuser obtained from weaves of colored PVC tubes or thermo-formed engineering compounds with polyester painted phospho-chromatated aluminum tubular internal frame. Inner diffuser in injectionmolded opal polycarbonate. “Galvanized” structural parts (base support, diffuser support, arms, brackets, levers and braces) for enhanced weather resistance. Gray painted body. Springs and main mechanical components also in special...

ROMEO OUTDOOR DESIGNED BY PHILIPPE STARCK TECHNICAL DATA SHEET: PAGE 112 descriPtion Wall or suspension luminaires for outdoor use providing direct and diffused light. The Outdoor range of luminaires has: - a diecast aluminum alloy wall or ceiling fitting with brilliant finish; - an injection-molded (UL-94 V0) polycarbonate (PC) cover rose; - a 316L stainless steel stem – polished; - an opal-colored, vacuum -formed internal (UL-94 V2) polycarbonate diffuser. Versions c1 and W: - diffuser support in injection-molded, opal-colored (UL-94 V0) polycarbonate; - crown support in injection-molded,...

TUBULAR BELLS PRO DESIGNED BY PIERO LISSONI TECHNICAL DATA SHEET: PAGE 120 descriPtion Ceiling luminaires for direct illumination. Body of the luminaire made of extrusion aluminium. Zoom lens available to regulate the opening grade of luminous beam. The LED version and the PRO versions have a crosshead shielded. Available finishes: white (09, 11), satin anodized aluminium (61, AS), anodized black (30, AN). Produktbeschreibung Deckenleuchten für direkte Beleuchtung. Leuchtenkörper aus stranggepresstem Aluminium. Zoom-Funktion zur Einstellung des Lichtstrahlöffnungswinkels. Die LED-Ausführung...

CLESSIDRA DESIGNED BY ANTONIO CITTERIO descriPtion Diffused direct/indirect-light wall lighting device. Body obtained by means of aluminium pressofusion and diffusers in PMMA. Aluminium wall attachment with cover in PA66. Outdoor version available in micaceous brown-painted or anodized black previously sandblasted with inox microspheres. High-efficiency lenses specially designed for the application, non-replaceable, availables with 20° or 40° beam. LamPs muLtichiP Led 2 X 3000K 600lm CRI80 - 8W PoWer suPPLy Wide range (100-240Volt) power pack integrated in the body. TECHNICAL DATA SHEET:...

WALLFLOWER DESIGNED BY MARCEL WANDERS descriPtion Standing fixture with direct light. Glass body with anodized aluminium fittings. Remote driver (not incuded). Available in transparent or acid etched glass. Protection level IP67. LamPs N.1 LED 72 lumen 3000 K, with side emitter lens. PoWer suPPLy Electronic driver remote (not included). standard comPLiance and QuaLity marks EN60598-1 European Technical Standards, and any subsequent additions. TECHNICAL DATA SHEET: PAGE 124 Produktbeschreibung Stehleuchte mit direktem Licht. Glaskörper mit anodisierten Aluminiumhalterungen. Ferntreiber...

MINI BUTTON DESIGNED BY PIERO LISSONI TECHNICAL DATA SHEET: PAGE 126 descriPtion Wall or ceiling fixture providing diffused lighting. Silicone elastomer dust and waterproof seal. Die-cast aluminum lamp body and wall fitting. Diffuser available in polycarbonate with opal finishes or in glass. LamPs HSGS type, G9 lamp holder, 25W. LeuchtmitteL Typ HSGS, Fassung G9, 25W. standard comPLiance and QuaLity marks EN60598-1 European Technical Standards, and any subsequent additions; ENEC Electrical Safety Mark. Produktbeschreibung Wand oder Deckenleuchte für diffuses Licht. Silikonkautschuk für...
